NEO Undercounter Ice Machine: Half Dice Cube

NEO Undercounter Ice Machine: Half Dice Cube

Built for operators who understand ice's critical role in their operations, the Manitowoc NEO Series Ice Machine sets a new industry standard for countertop ice makers with fully enhanced ice-making performance. Its design is more compact and rational, yet ice production and storage capacities remain comparable to previous generations. Boasting exceptional energy efficiency, most models meet U.S. Energy Star standards—reducing water usage by 25% and electricity consumption by 10% to effectively lower store operating costs. During development, particular focus was placed on operational stability; through robust internal structures, proven vertical evaporator plates, and cleverly designed modular construction, it achieves high-efficiency ice production with easier cleaning and maintenance. It is widely used in brand hotel executive lounges, quick-service chains, small-to-medium coffee chains, bakeries, premium coffee & bar lounges, and other establishments.

  • Product Details
  • Video
  • Specification
  • Service Support

Product details:

  • User-Friendly Interactive Panel: Clear icons and indicator lights enable better monitoring of machine status.
  • Programmable Timed Ice Making: Schedules ice production based on store foot traffic to reduce energy costs.
  • Easy Cleaning & Maintenance: Tool-free, quick and effective cleaning of removable water tanks, water distributors and air filters.
  • Antimicrobial Food Zone: Key plastic components with AlphaSan™ antimicrobial agent effectively prevent surface bacterial growth.
  • Patented Cleaning & Sanitization Technology: Simplifies machine cleaning and sanitization, lowering maintenance costs.
  • Corrosion & Fingerprint-Resistant External Composite Material: Maintains a clean and sleek appearance even with long-term use.
  • Optional LUMINICE™ Antimicrobial Device: Inhibits growth of yeast, bacteria and other microorganisms, preserving a clean ice-making environment.
  • Modular Body Design: Tool-free disassembly and assembly of machine housing for easy maintenance and repairs, reducing upkeep expenses.

NEO Undercounter Ice Machine: Half Dice Cube Overview

NEO Series Undercounter Ice Machine 140lbs.

24Hs Ice Production: 62 kg
Ice Storage: 40 kg / 90 lbs.
Refrigerant: R404A
Electric Configration:  115V/60Hz/1ph; 230V/50Hz/1ph
Cooling Configration: Air

NEO Series Undercounter Ice Machine 190lbs.

24Hs Ice Production: 88 kg
Ice Storage: 40 kg / 90 lbs.
Refrigerant: R404A
Electric Configration: 115V/60Hz/1ph; 230V/50Hz/1ph
Cooling Configration: Air

NEO Series Undercounter Ice Machine 240lbs.

24Hs Ice Production: 99 kg
Ice Storage: 40 kg / 90 lbs.
Refrigerant: R404A
Electric Configration: 115V/60Hz/1ph; 230V/50Hz/1ph
Cooling Configration: Air / Water

NEO Series Undercounter Ice Machine 310lbs.

24Hs Ice Production: 132 kg
Ice Storage: 54 kg / 119 lbs.
Refrigerant: R404A
Electric Configration:  115V/60Hz/1ph; 230V/50Hz/1ph
Cooling Configration: Air / Water

Videos

NEO Cleaning Video

Specification

Product Model Electric Configration 24Hs Ice Production Ice Storage Refrigerant Touch Screen Machine Demesion
W x D x H		 Cooling Configration Power Usage kWh/100lbs.
(45.4 kgs ) of Ice		 Potable Water Usage /100lbs.
(45.4 kgs ) of Ice		 Typical Ice Bin & Storage Parts Manual
UYF0140 UYF0140A
UYF0140A (60Hz)		 230V/50Hz/1ph
115V/60Hz/1ph		 62 kg / 137 lbs. (air cooled)
62 kg / 137 lbs. (air cooled)		 40 kg / 90 lbs.
40 kg / 90 lbs.		 R404A
R404A		 No
No		 66.04 x 72.4 x 97.8 cm
66.04 x 72.4 x 97.8 cm		 air cooled
air cooled 		9.2
9.2		 16.7 gal
16.7 gal		 D040, 40 kg / 90 lbs.
D040, 40 kg / 90 lbs.		 Download
UYF0190 UYF0190A
UYF0190A (60Hz)		 230V/50Hz/1ph
115V/60Hz/1ph		 88 kg / 193 lbs. (air cooled)
88 kg / 193 lbs. (air cooled)		 40 kg / 90 lbs.
40 kg / 90 lbs.		 R404A
R404A		 No
No		 66.04 x 72.4 x 97.8 cm
66.04 x 72.4 x 97.8 cm		 air cooled
air cooled 		8.3
8.3		 21.6 gal
21.6 gal		 D040, 40 kg / 90 lbs.
D040, 40 kg / 90 lbs.		 Download
UYF0240 UYF0240A
UYF0240A (60Hz)
UYF0240W (60Hz)		 230V/50Hz/1ph
115V/60Hz/1ph
115V/60Hz/1ph		 99 kg / 219 lbs. (air cooled)
99 kg / 219 lbs. (air cooled)
94 kg / 207 lbs. (water cooled)		 40 kg / 90 lbs.
40 kg / 90 lbs.
40 kg / 90 lbs.		 R404A
R404A
R404A 		No
No
No 		66.04 x 72.4 x 97.8 cm
66.04 x 72.4 x 97.8 cm
66.04 x 72.4 x 97.8 cm		 air cooled
air cooled
water cooled		 - - D040, 40 kg / 90 lbs.
D040, 40 kg / 90 lbs.
D040, 40 kg / 90 lbs.		 Download
UYF0310 UYF0310A
UYF0310A (60Hz)
UYF0310W (60Hz)		 230V/50Hz/1ph
115V/60Hz/1ph
115V/60Hz/1ph		 132 kg / 290 lbs. (air cooled)
132 kg / 290 lbs. (air cooled)
133 kg / 293 lbs. (water cooled)		 54 kg / 119 lbs.
54 kg / 119 lbs.
54 kg / 119 lbs.		 R404A
R404A
R404A 		No
No
No		 76.20 x 72.4 x 97.8 cm
76.20 x 72.4 x 97.8 cm
76.20 x 72.4 x 97.8 cm		 air cooled
air cooled
water cooled		 7.2
7.2
5.5		 15.5 gal
15.5 gal
15.5 gal		 D054, 54 kg / 119 lbs.
D054, 54 kg / 119 lbs.
D054, 54 kg / 119 lbs.		 Download
Notice:
24-hour ice production test conditions: Ambient temperature 21°C / 70°F, water temperature 10°C / 50°F, 220V 50Hz;
Data on product cards are actual measurements for air-cooled models. For water-cooled models, split-type units and other cooling types, please refer to the product specification sheet.
​Power consumption per 100 lbs. of ice test conditions: Ambient temperature 32°C / 90°F, water temperature 21°C / 70°F.

NEO Undercounter Ice Machine: Half Dice Cube Data Search& Download

NEO Series User Manual
CN EN
NEO Series Service Manual
CN EN
